Model 4330
SELECTION
This solenoid is designed
for a variety of Automation Control tasks with the
use of DC power. The Force Output - Stroke - Watts
Used table is designed to assist our customers to
select the required solenoid. Then the Coil
Selection Table is used to select the necessary coil
for the available voltage.
TO ORDER
To order please specify the
Model, Stroke and Coil.
|
MODEL
|
STROKE
|
COIL
|
|
|
4430
|
.250
|
4334-27=
|
4330-.250.-4334-27
|
This is a model 4430
solenoid with the standard mounting shown above,
having a stroke of .250" and having a 20 ohm coil
which will operate continuously at 24VDC with a 28.8
watt power consumption or intermittently at 48VDC
with a 115 watt power consumption.
LINEAR FORCE OUTPUT IN
POUNDS vs STROKE AND INPUT POWER
|
STROKE IN INCHES
|
LINEAR FORCE OUT PUT
IN POUNDS
|
|
CONTINOUS DUTY
|
INTERMITTENT DUTY
|
|
|
|
|
50%
|
10%
|
1%
|
|
.750
|
0
|
0.1
|
0.2
|
(0.4)
|
(1.0)
|
(2.5)
|
|
.500
|
0.2
|
0.6
|
1.0
|
(1.2)
|
(2.5)
|
(4.5)
|
|
.400
|
0.3
|
0.7
|
1.2
|
(1.7)
|
(3.7)
|
(6.0)
|
|
.300
|
0.5
|
1.2
|
1.7
|
(2.5)
|
(5.0)
|
(11)
|
|
.250
|
0.8
|
1.7
|
2.5
|
(3.5)
|
(7.0)
|
(13)
|
|
.200
|
1.0
|
2.3
|
3.2
|
(4.5)
|
(8.5)
|
(15)
|
|
.150
|
1.5
|
3.5
|
5.0
|
(7.0)
|
(11)
|
(19)
|
|
.100
|
3.3
|
6.0
|
9.0
|
(11)
|
(20)
|
(25)
|
|
.050
|
7.0
|
15
|
20
|
(24)
|
(33)
|
(43)
|
|
.025
|
12.5
|
23
|
30
|
(36)
|
(44)
|
(53)
|
|
WATTS
|
10W
|
20W
|
30W
|
40W
|
80W
|
160W
|
COIL SELECTION TABLE FOR
RESISTANCE AND POWER CONSUMPTION
|
COIL PART NO.
|
RESISTANCE OHMS at
72 F
|
WATTS AT 72 Deg. F
COIL TEMPPERATURE
|
|
6V
|
12V
|
24V
|
48V
|
120V
|
|
(Red
text) indicates
intermittent duty
|
|
4334-17
|
0.24
|
(150.0)
|
-
|
-
|
-
|
-
|
|
4334-18
|
0.4
|
(90.0)
|
-
|
-
|
-
|
-
|
|
4334-19
|
0.7
|
(51.4)
|
-
|
-
|
-
|
-
|
|
4334-20
|
1.0
|
(36.0)
|
(144.0)
|
-
|
-
|
-
|
|
4334-21
|
1.6
|
22.5
|
(90.0)
|
-
|
-
|
-
|
|
4334-22
|
2.3
|
15.7
|
(62.6)
|
-
|
-
|
-
|
|
4334-23
|
3.4
|
10.6
|
(42.4)
|
(169.4)
|
-
|
-
|
|
4334-24
|
5.3
|
-
|
27.2
|
(108.7)
|
-
|
-
|
|
4334-25
|
8.7
|
-
|
16.6
|
(66.2)
|
-
|
-
|
|
4334-26
|
13
|
-
|
11.1
|
(44.3)
|
(177.2)
|
-
|
|
4334-27
|
20
|
-
|
-
|
28.8
|
(115.2)
|
-
|
|
4334-28
|
31
|
-
|
-
|
18.6
|
(74.3)
|
-
|
|
4334-29
|
47
|
-
|
-
|
12.3
|
(49.0)
|
-
|
|
4334-30
|
78
|
-
|
-
|
-
|
29.5
|
(184.6)
|
|
4334-31
|
130
|
-
|
-
|
-
|
17.7
|
(110.8)
|
|
4334-32
|
200
|
-
|
-
|
-
|
11.5
|
(72.0)
|
|
4334-33
|
310
|
-
|
-
|
-
|
-
|
(46.5)
|
|
4334-34
|
530
|
-
|
-
|
-
|
-
|
27.2
|
|
4334-36
|
880
|
-
|
-
|
-
|
-
|
16.4
|
VARIATIONS
Nearly every
solenoid needs to be customized to fit specific
applications. There are available modifications for
mounting, stroke, coil resistance, lead length, lead
termination, push or pull configurations, spring
returns, etc. Please specify what will make your
application work and we will modify the solenoid to
fit your needs.
|
